FranklinWH Agate Energy Management Device

SKU Agate
Original price $1,890.00 - Original price $1,890.00
Original price
$1,890.00
$1,890.00 - $1,890.00
Current price $1,890.00

In Stock & Ready to Ship

Orders ship in 1-2 business days with a 4-7 day ETA*. Returns are accepted within 30 days. View Policy Here. *Exclusions may apply

Price Match Guarantee at OffGrid Lux

At OffGrid Lux, we're committed to offering you the best prices online. That's why we have a Price Match Guarantee in place. If you find a lower price for the same product elsewhere, we'll match or beat it to ensure you get the best value.

For full details on our Price Match Guarantee, including eligibility criteria and how to request a price match, please click here to view our complete policy.

Shipping & Order Policy at OffGrid Lux

When you place an order, we confirm stock availability before charging your card. Orders typically process within 1-2 business days, and shipping is fast—most orders arrive within 4-7 days. We use reliable third-party carriers and provide tracking information promptly.

For more details, click here to view our full Shipping Policy.

Refunds & Returns at OffGrid Lux

We're committed to your happiness with every purchase. Need assistance? Just reach out. You have 30 days from delivery to return items in their original condition. We process refunds promptly, usually within 3 business days of receiving your return.

For more info, check out our full Returns & Refunds Policy here.

Franklin Home Power is built to address the evolving needs of homeowners now and in the future. It surpasses the basic requirement for safe and dependable backup power by combining the largest AC battery capacity available with the smartest control technology in the industry.

Features

  • aPower is the AC battery with built-in advanced inverter
  • aGate is the energy management device connecting the grid, the loads, the generator and the solar system
  • FranklinWH App allows for seamless monitoring of your whole home energy
  • Reliable - Exceeds performance standards, backed by 12-year warranty
  • Scalable - Highest system density allows up to 15 units for 204 kWh1
  • Hassle-Free - Remote monitoring and user-friendly app limits O&M
  • Flexible - Technology-agnostic system can be used with any solar inverter
  • Simplified - Pre-assembled for fast, easy one-step installation

Specifications

  • Series/Model: aGate X-01-AU / aPower X-01-AU
  • Battery Chemistry: Lithium Iron Phosphate
  • Usable System Energy: 13.6 kWh per unit, scalability up to 15 units
  • Aggregate Throughput: 43 MWh
  • Nominal AC Voltage: 230/240 V, 50 Hz
  • Maximum Real Power: 5 KW
  • Maximum Apparent Power: 5 kVA
  • Rated Output Current: 21.7 A
  • Rated Backup Output Current: 21.7 A
  • Maximum Supply Fault Current: 10 kA
  • Maximum Output Fault Current: 32 A
  • Battery DC Voltage: 51.2 V
  • Inverter Maximum Efficiency: 96.5%
  • Round Trip Efficiency: 89%
  • Noise Emission (Optimal): <30 dB (A)
  • Communication Method: Ethernet / 4G / Wi-Fi / Bluetooth
  • User Interface: FranklinWH App
  • Dimensions: 650 mm (H) x 480 mm (W) x 160 mm (D)
  • Installation: Wall / Floor Mount
  • Maximum Over Current Protection Device Per aPower Branch: 32 A
  • Maximum Over Current Protection Device Per Solar Branch: 63 A
  • Maximum Grid Input Over Current Protection Device: 100 A
  • Maximum Generator Input Over Current Protection Device: 100 A
  • Maximum Over Current Protection Device Per Smart Circuits Branch: 63 A
  • Coupling: AC Coupled
  • Feed-In Phase: Single Phase
  • Connection Support: L/N/PE
  • Operating Temperature: -20 to 50°C, -10 to 45°C (Storage)
  • Operating Humidity: Up to 95% RH, Condensing
  • Altitude: 4000 m
  • Ingress Rating: IP55
  • Standards:
    • IEC/EN62109-1
    • IEC/EN62109-2
    • IEC/EN62477-1
    • AS/NZS 4777.2:2020
    • IEC62040-1
    • IEC/EN61439-1
    • IEC/EN61439-2
    • RoHS Directive 2011/EU
  • Warranty: 12 Years

Documents
