MRCOOL 48K BTU, 4 Ton, 16.5 SEER2 Hyper Heat Central Ducted Condenser (CENTRAL-48-HP-C-230B00-O)
This product only includes a condenser.
The 48K MRCOOL® Hyper Heat Central Ducted Condenser is crafted to provide outstanding performance in even the most extreme climates, from icy winters to scorching summers. This Hyper Heat system utilizes DC Inverter technology and variable speed functionality to deliver consistent, high-quality operation. With a SEER2 rating of up to 16.5 and an HSPF2-4 rating of up to 9.5, it offers powerful heating and cooling while maximizing energy efficiency. A MRCOOL® Smart thermostat is included, giving you complete control over your indoor environment with ease.
The 48K MRCOOL® Hyper Heat Central Ducted Condenser is compatible with the 48K MRCOOL® VersaPro® Central Ducted Air Handler. The air handler is built for flexibility, supports various installation options, and is compatible with an optional heat kit for added capability. The system features R-454B refrigerant, a sustainable choice that minimizes its impact on the environment. Durability is a hallmark of the outdoor heat pump, constructed with a painted galvanized steel exterior for long-term resilience. The air handler is thoughtfully designed with a compact form, slide-out blower, and self-diagnostic panel to streamline maintenance and troubleshooting.
Enjoy peace of mind with the system’s 10-year warranty, covering the compressor, parts, and labor. The labor warranty activates automatically upon installation, so no registration is required. Enhance your home’s comfort with the efficient and reliable 48K MRCOOL® Hyper Heat Central Ducted Condenser today!
Product Specifications
MRCOOL Hyper Heat 2nd Gen 48K BTU, 4 Ton, 16.5 SEER2 Central Ducted Condenser (CENTRAL-48-HP-C-230B00-O) Product Specifications
Dimensions
|
16.34" D x 38.39" H x 38.58" W
|
SEER2
|
16.5
|
EER2
|
10.5
|
HSPF-4
|
9.5
|
HSPF-5
|
8
|
CFM
|
3037.1
|
Tonnage
|
4
|
Cooling Capacity (BTU)
|
48000
|
Heating Capacity (BTU)
|
50000
|
Voltage (V)
|
208-230
|
Phase
|
1
|
Cycle
|
60
|
Max Fuse Breaker (A)
|
40
|
Min Circuit Ampacity (A)
|
38
|
Color
|
gray
|
Refrigerant Type
|
R454B
|
Refrigerant Volume (OZ)
|
134.04
|
Decibel Rating (DBA)
|
65
|
Liquid Line Size
|
3/8
|
Suction Line Size
|
3/4
|
WIFI Compatibility
|
Yes
|
APP Compatibility
|
Yes
|
ETL Certified
|
Yes
|
Energy Star Certified
|
Yes
|
AHRI Certified
|
Yes
|
Base Parts Warranty
|
10 Years
|
Base Compressor Warranty
|
10 Years
|
Base Labor Warranty
|
10 Years
|
Contains Electronics
|
Yes
|
Contains Chemicals
|
Yes
|
Contains Compressed Gas
|
Yes
|
Net Weight (Lbs)
|
201.06
|
Gross Depth (In)
|
19.68
|
Gross Height (In)
|
42.52
|
Gross Width (In)
|
45.08
|
Gross Weight (Lbs)
|
232.36
|
Product Manual
Product Warranty
MRCOOL Limited Lifetime Warranty
LIMITATIONS OF WARRANTIES
Q1 How do I register my warranty?
Answer: Go to here to file your warranty.
Q2 How do I find the AHRI number of my unit?
Answer: You can find links to the AHRI certificates on the documentation page at mrcool.com/documentation.
